V10TF(JIS 10K) FF type
  • V10TF(JIS 10K) FF type

V10TF(JIS 10K) FF type

Tổng quan

Part No Model No

Thread
(Rp)

 φD φC φb φa t T Bolt holes
n(Number) φh
14100181 V10TF-FF-04 1/2 95 70 30 28 12 16 4 15
14100182 V10TF-FF-06 3/4 100 75 36 34 14 20 4 15
14100183 V10TF-FF-08 1" 125 90 44 42 14 20 4 19
14100184 V10TF-FF-10 1"1/4 135 100 53 51 16 22 4 19
14100185 V10TF-FF-12 1"1/2 140 105 60 57 16 24 4 19
14100186 V10TF-FF-16 2" 155 120 73 70 16 24 4 19
14100187 V10TF-FF-20 2"1/2 175 140 91 81 18 27 4 19
14100188 V10TF-FF-24 3" 185 150 105 100 18 30 8 19
14100189 V10TF-FF-32 4" 210 175 130 128 18 36 8 19
