LTM 1040-2.1 - More lifting capacity on two axles.

The LTM 1040-2.1 delivers outstanding lifting capacities over its entire operating range. Its long, 4-piece telescopic boom can be extended with infinite adjustment and quickly to any length using a time-tested hydro-mechanical telescoping system. The telescoping process can also be completed whilst there is a load on the boom. A folding jib can be used to achieve a radius of up to 39 metres. In comparison to the slightly smaller LTM 1030-2.1, this mobile crane can handle five tonnes more on its hook.









What's inside

  • Up, up and away:

    Hoist height of up to 144 ft / 44 m possible with folding jib attached.

  • 4-piece boom:

    The telescopic boom can be extended quickly using the time-tested hydro-mechanical telescoping system.

  • Lower fuel consumption:

    ECOmode reduces fuel consumption by up to 10%.

  • A great view:

    The operator can monitor the setup processes using the BTT remote control.

  • Optional VarioBase:

    The prize-winning VarioBase support system is available as an option to enhance safety.

Technical data

Max. load capacity 45 US t
at radius 9 ft
Telescopic boom from 34 ft
Telescopic boom up to 115 ft
Lattice jib from 31 ft
Drive engine/make Cummins
Drive engine 6-Zylinder-Diesel
Drive engine/power 280 hp
Number of axles 2
Drive/Steering standard 4 x 4 x 4
Driving speed 53.00 mph
Total ballast 14,300 lb




Downloads

Technical Data - Mobile crane LTM 1040-2.1 [ft/lb]

PDF (4.7 MB)
